MIL-R-23016(Wep)
16 October 1961
MILITARY SPECIFICATION
RADIO SET AN/ARC-94
This specification has been approved by the
Bureau of Naval Weapons, Department of the Navy
SCOPE
1.
1.1
Scope:
The equipment covered by this specification shall provide facilities
to effect two-way radio communications between aircraft and properly
equipped surface stations or other aircraft. Transmission and recep-
tion shall be in the single sideband mode with or without carrier
suppression and shall be accomplished on the same antenna. Simul-
taneous transmission and reception is not required. Power amplifier
automatic tuning is required throughout the frequency range of the
equipment.
1.2
Classification:
The equipment covered by this specification shall consist of the
following items:
Maximum
Type
Allowable
Appl.
Item
Designation
Wt. Lbs
Paragraph
Receiver-Transmitter
RT-648/ARC-94
52
3.3.4.1
Control
C-3940/ARC-94
2
3.3.4.2
Mounting
MT-2641/ARC-94
5
3.3.4.3
APPLICABLE DOCUMENTS
2.
2.1
General:
The following documents of the issue in effect on the date of
invitation for bid form a part of this specification to the extent
specified herein.
Specifications
Military
Anodic Coatings, for Aluminum and Aluminum Alloys
MIL-A-8625
