MIL-DTL-85670 Antenna, Broadband As-3191/A, As-3792/A, And As-3793/AThis specification establishes the design, performance, and acceptance requirements for AS-3191/A, AS-3792/A, and AS-3793/A broadband antennas, hereinafter referred to as the antenna. The separately nomenclatured antennas differ only in surface finish and color. The antenna is a universal blade type to be used in aircraft equipped with the AN/ARC-182\(V\) radio set. The antenna is an aircraft fuselage mounted blade enclosed element. The antenna is a broadband, fix tuned, exhibits omnidirectional radiation pattern, and is vertically polarized for radiating and receiving radio waves in the 30-88 MHz, 108-174 MHz, and 225-400 MHz communication bands.
