INCH-POUND
MIL-DTL-85670D
17 September 2012
SUPERSEDING
MIL-DTL-85670C
16 May 2007
DETAIL SPECIFICATION
ANTENNA, BROADBAND
AS-3191/A, AS-3792/A, AND AS-3793/A
This specification is approved for use within the Naval Air Systems
Command, Department of the Navy, and is available for use by all
Departments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification establishes the design, performance, and acceptance requirements for AS-3191/A,
AS-3792/A, and AS-3793/A broadband antennas, hereinafter referred to as the antenna. The separately
nomenclatured antennas differ only in surface finish and color. The antenna is a universal blade type to be used in
aircraft equipped with the AN/ARC-182(V) radio set. The antenna is an aircraft fuselage mounted blade enclosed
element. The antenna is a broadband, fix tuned, exhibits omnidirectional radiation pattern, and is vertically polarized
for radiating and receiving radio waves in the 30-88 MHz, 108-174 MHz, and 225-400 MHz communication bands.
1.2 Part or Identifying Number (PIN). The antennas covered by this specification are AS-3191/A, AS-3792/A, and
AS-3793/A; differ only in surface finish and color.
PIN
Exterior finish
AS-3191/A
lusterless black epoxy (see 3.4.7 a)
Or
AS-3792/A
Gloss white epoxy (see 3.4.7 b)
Or
AS-3793/A
Aircraft green (see 3.4.7 c)
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements documents cited in sections 3 and 4 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract (see 6.2).
Comments, suggestions or questions on this document should be addressed to DLA Land and Maritime, ATTN:
VAT, Post Office Box 3990, Columbus, OH 43218-3990, or emailed to Tubesamps@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.dla.mil.
AMSC N/A
FSC 5821
